TPA3116D2DADR 32HTSSOP SMD IC AMP CLASS D STER 50W

• Output Power:
  • 2 × 50 W into a 4-? Bridge-Tied Load (BTL) at 21 V
  • 2 × 30 W into an 8-? BTL at 24 V
• Supply Voltage Range: 4.5 V to 26 V
• Efficiency: Greater than 90%, reducing the need for extensive heat sinking
• Modulation Options: Supports multiple switching frequencies up to 1.2 MHz to avoid AM radio interference
• Protection Features: Integrated safeguards against overvoltage, undervoltage, overtemperature, DC detection, and short circuits, with error reporting
• Package: 32-pin HTSSOP with a thermally enhanced PowerPAD for improved heat dissipation

Features:

• Advanced oscillator/PLL circuit for flexible switching frequency selection
• Feedback power-stage architecture with high Power Supply Rejection Ratio (PSRR) to minimize power supply noise impact
• Programmable power limit to protect speakers and enhance system reliability
• Supports both differential and single-ended inputs
• Configurable for stereo or mono operation, with a single-filter mono configuration available

Applications:

• Mini and micro component audio systems
• Speaker bars and docking stations
• Aftermarket automotive audio systems
• Consumer audio equipment
