Dual Non-Inverting Channels: Contains two independent channels, each capable of driving a low-side MOSFET. The input type is non-inverting.High Peak Output Current: Provides a high peak output current of 9A.Wide Operating Supply Voltage: Operates from a wide supply voltage range from 4.5V to 18V.High Continuous Output Current: Supports a continuous output current of up to 2A.TTL/CMOS Input Compatible: The inputs are compatible with both TTL and CMOS logic levels.Low Supply Current: Consumes low supply current, typically 200µA with a logic '1' input and 55µA with a logic '0' input.Low Output Impedance: Features low output impedance, typically 1.4?.Latch-Up Protected: Designed to be highly latch-up protected, capable of withstanding 1.5A output reverse current.Input Withstands Negative Inputs: The input will withstand negative inputs up to 5V.Fast Switching Speeds: Offers fast rise and fall times, typically 30ns with a 4,700 pF load.Short Propagation Delays: Features short propagation delays, typically 30ns.Noise Immunity: Includes 300mV of hysteresis built into the input for noise immunity.
