Dual Receiver: It consists of two independent single-ended line receivers.TTL-Compatible: Both the strobe inputs and the outputs are compatible with TTL (Transistor-Transistor Logic) logic levels.Adjustable Reference Voltage: The switching threshold (reference voltage) can be set externally, allowing optimization of noise immunity for the specific system. The adjustable range is 1.5 V to 3.5 V.Low Input Current: The device requires low input current (less than 100 µA), making it suitable for party-line (data-bus) applications.Common Reference and Strobe: Features a common reference-voltage pin and a common strobe for both receivers.Single 5V Supply: Operates from a single +5V power supply.Operating Temperature: Characterized for operation from 0°C to 70°C.Sensitivity: Offers a sensitivity of ±100 mV.
