High-Speed Response: Provides high-speed data transmission, typically up to 1 Mbps or 10 MBit/s depending on the variant. It boasts fast rise and fall times, typically 0.2 µs and 0.2 µs respectively.High Common Mode Rejection (CMR): Offers excellent rejection of common-mode noise, with a minimum CMR of 15 kV/µs or -15 kV/µs. This is particularly important for reliable operation in noisy environments.High Isolation Voltage: Provides high electrical isolation between input and output, typically 5.0 kVrms. This ensures safety in high-voltage applications and prevents interference between circuits operating at different potentials.Photodiode and OPIC Technology: Uses a photodiode and OPIC (Optical IC) chip combination for the light reception and signal processing. OPIC technology integrates the light-detecting element and signal processing circuit onto a single chip. This design allows for faster transfer rates and better performance than conventional phototransistor optocouplers.TTL Compatibility: The output of the OPIC chip is typically compatible with Transistor-Transistor Logic (TTL) levels.Operating Temperature Range: Operates over a wide temperature range, typically -55°C to +100°C or -40°C to +100°C.Safety Approvals: Recognized by UL (file No. E64380) and approved by VDE.Lead-Free and RoHS Compliant: Complies with environmental regulations.
