Half-bridge configuration: Both drivers control a high-side and a low-side power device (MOSFET or IGBT) in a half-bridge arrangement.High Voltage Operation: Capable of operating with high-side applications up to +600V.Bootstrap Operation: Feature a floating channel designed for bootstrap operation, enabling the high-side driver.Input Logic Compatibility: The logic input is compatible with standard CMOS or LSTTL output, down to 3.3V logic.Gate Drive Supply Range: Offer a gate drive supply range from 10V to 20V.Undervoltage Lockout (UVLO): Include UVLO to prevent operation at insufficient voltage levels.Cross-conduction prevention logic: Built-in logic prevents the high-side and low-side switches from turning on simultaneously, minimizing the risk of short circuits.Internally set deadtime: The IC includes an internally configured deadtime, which introduces a delay between switching the high-side and low-side transistors, further preventing simultaneous conduction and enhancing reliability.Matched propagation delay: The propagation delay for both channels is matched to maintain timing accuracy.
