Description: FIXED IND 960NH 19.4A 1.9 MOHM
Detailed Description: 960nH Unshielded Wirewound Inductor 19.4A 1.9 milliohm Radial
Type: Wound
Material - Core: Iron Powder
Inductance: 960nH
Tolerance: ±20%
Rated current: 19.4A
Current - saturation value: 40A
Shielding: No shielding
DC resistance (DCR): 1.9 milliohms
Q value at different frequencies:-
Working temperature: -40°C ~ 105°C
Inductor frequency - test: 100kHz
Mounting type: Through hole
Package/Casing: Radial
Size/Dimensions: 0.539" long x 0.472" wide (13.70mm x 12.00mm)
Height - Mounted (max): 0.354" (9.00mm)
Other names: 513-1519 HCPT1309-1R0-R-ND
