High Noise Immunity: Characterized by a high common mode rejection (CMR) of 20 kV/µs minimum, ensuring stable operation even in noisy environments. This is achieved using ON Semiconductor's patented coplanar packaging technology, Optoplanar, and optimized IC design.High Output Current: Capable of driving most 800V/20A IGBT / MOSFETs with a 1.0 A output current.High Isolation Voltage: Provides robust electrical isolation, typically 5000 Vrms for 1 minute, as recognized by safety standards like UL1577. DIN EN/IEC60747?5?5 approved.Fast Switching Speed: Features a maximum propagation delay of 500 ns and a maximum pulse width distortion of 300 ns.Wide Supply Voltage Range: The output supply voltage can range from 15V to 30V.P-channel MOSFETs at Output Stage: The use of P-channel MOSFETs at the output stage enables the output voltage to swing close to the supply rail.Under Voltage Lockout (UVLO) with Hysteresis: Prevents the IC from operating at insufficient supply voltages, ensuring reliable performance.Wide Operating Temperature Range: Operates over an extended industrial temperature range of ?40°C to 100°C.Compact DIP-8 Package: Suitable for through-hole mounting applications.
