Output Type: NPN transistor outputWiring Configuration: 3-wire systemOperating Voltage: 4.5 to 28 VDCLoad Current: Up to 40 mAVoltage Drop: 0.8 V or less at 10 mA load current (2 V or less at 40 mA)Current Consumption: 10 mA or lessIndicator Light: Red LED illuminates upon detection of the magnetic fieldResponse Time: 1 ms or lessProtection Rating: IP67, ensuring dust-tight sealing and protection against temporary immersion in waterOperating Temperature Range: -10 to 60°CImpact Resistance: 1000 m/s²Vibration Resistance: 10 to 150 Hz, at the smaller amplitude, 1.5 mm or 20 m/s² in X, Y, Z directions for 2 hours each (De-energized)
