Operating Frequency: Adjustable from 387 MHz to 464 MHz; commonly set to 433 MHz.Supply Voltage: 1.8 V to 3.6 V.Maximum Transmission Power: 10 mW (+10 dBm).Current Consumption:- Transmission: Approximately 29 mA at maximum power.
- Reception: Approximately 16 mA.
Communication Interface: SPI (Serial Peripheral Interface) with data rates up to 10 Mbps.Receiver Sensitivity: Up to -110 dBm at 1.2 kbps data rate.Modulation Support: 2-FSK, GFSK, and MSK.Antenna Interface: Standard SMA connector with 50? impedance.
