Integrated Overvoltage Protection (Crowbar Technology): This is a standout feature, enabling the device to absorb overvoltage energy, such as surges caused by lightning or switching inductive loads. This built-in protection means you generally don't need external components like snubber circuits or varistors, which simplifies design and reduces component count. It also helps meet IEC 61000-4-5 surge standards.High Noise Immunity: The device provides strong immunity against static dV/dt (rate of change of voltage over time) and IEC 61000-4-4 burst disturbances, ensuring reliable operation in noisy electrical environments.Direct Microcontroller Interface: It features a gate level shifter driver that allows direct interfacing with a microcontroller, eliminating the need for additional interface components and simplifying circuit design. This can reduce component count by up to 80%.Low Holding Current: The holding current is low, typically 10mA, which allows the device to turn off quickly when the control signal is removed.Common Package Tab Connection: The TO-92 package allows for the connection of multiple ACS devices on the same cooling pad, simplifying thermal management in applications with multiple switches.Compact TO-92 Package: The TO-92 package provides a small footprint for space-constrained applications.Wide Operating Temperature Range: It operates within a temperature range of -40°C to +125°C.
Repetitive Peak Off-State Voltage (VDRM/VRRM): 600 V
RMS On-State Current (IT(RMS)): 0.8 A
Non-Repetitive Surge Peak On-State Current (ITSM): 7.3 A (for 20 ms at 50 Hz)
Gate Trigger Current (IGT): Maximum 10 mA
Holding Current (IH): Maximum 10 mA
Critical Rate of Rise of On-State Current (dI/dt): 100 A/µs
Static dV/dt: Minimum 2000 V/µs
Features:
Overvoltage Protection: Incorporates crowbar technology to absorb inductive turn-off energy, enhancing robustness against voltage surges.
High Noise Immunity: Exhibits strong resistance to electrical noise, with a static dV/dt capability exceeding 2000 V/µs.
Direct Microcontroller Interface: Allows direct interfacing with microcontrollers without the need for additional protection components like snubbers or varistors, thereby reducing component count by up to 80%.
