model: PIC12F675-I/MD
Is it lead-free? Lead Free
Number of needles: 8
Risk Level: 0.81
With ADC: YES
Other features: CAN ALSO
OPERATE AT 4MHZ AT 2VMIN SUPPLY AND 10MHZ AT 3V MIN SUPPLY
Bit Size: 8
CPU Series: PIC
Maximum clock
frequency: 20 MHz
DAC Channels: NO
DMA channels: NO
External data bus
width:
Format: FLOATING-POINT
length: 4
mm
Low Power Mode: NO
Moisture Sensitivity
Level: 1
Number of external
interrupt devices: 1
Number of I/O lines: 6
Number of terminals: 8
Number of timers: 2
On-chip data RAM
width: 8
On-chip program ROM
width: 14
Maximum Operating
Temperature: 85 °C
Minimum Operating
Temperature: -40 °C
PWM Channels: NO
Package body
material: PLASTIC/EPOXY
Package code: HVSON
Peak Reflow
Temperature (Celsius): 260
power supply: 2.5/5V
RAM (bytes): 64
ROM (word): 1024
ROM Programmability: FLASH
Filter level: TS 16949
Maximum seat height: 1 mm
speed: 20
MHz
Subcategories: Microcontrollers
Maximum slew rate: 3 mA
Maximum supply
voltage: 5.5 V
Minimum supply
voltage: 4.5 V
Nominal supply
voltage: 5 V
Surface Mount: YES
technology: CMOS
Temperature Rating: INDUSTRIAL
Terminal surface: Matte Tin (Sn)
Terminal type: NO LEAD
Terminal Pitch: 0.8 mm
Terminal Location: DUAL
Maximum time at peak
reflow temperature: 40
width: 4
mm
uPs/uCs/peripheral
integrated circuit types: MICROCONTROLLER,
RISC
