Standard Compliance: Meets or exceeds the requirements of ANSI TIA/EIA-422-B, TIA/EIA-423-B, and ITU Recommendations V.10 and V.11.Common-Mode Range and Sensitivity: Features a ±7-V common-mode range with a ±200-mV sensitivity. The related AM26LS33A has a ±15-V common-mode range with ±500-mV sensitivity.Input Hysteresis: Includes a typical input hysteresis of 50 mV, enhancing noise immunity.Single Supply Operation: Operates from a single 5-V supply.Low-Power Schottky Circuitry: Utilizes low-power Schottky circuitry for efficient operation.3-State Outputs: Outputs can be set to a high-impedance state, allowing direct connection to bus-organized systems.Complementary Output-Enable Inputs: Has complementary output-enable inputs.Input Impedance: Provides a minimum input impedance of 12 k?. Some sources cite it as 15 k?.Open Input Fail-Safe: Features open input fail-safe, ensuring outputs are high if inputs are open.Performance Comparison: Compared to the AM26LS32 and AM26LS33, the AM26LS32A incorporates an additional amplification stage to improve sensitivity. However, this increases the propagation delay, though it does not affect interchangeability in most applications.Operating Temperature Range: The AM26LS32AC is characterized for operation from 0°C to 70°C. Other variants, such as the AM26LS32AI, are characterized for operation from -40°C to 85°C.
